| 产地 | 浙江 |
|---|---|
| 电流 | 交流 |
| 电源电压 | 380V |
| 工作电压 | 380V |
| 激光功率 | 1200W |
| 控制方式 | 自动 |
| 用途 | 切割 |
| 作用对象 | 金属 |
| 品牌 | 欣睿激光 |
| 型号 | XR-FLC1200 |
| 切割头 | 激光头 |
●高性能，进口原厂封装光纤激光器，性能稳定，使用寿命可达10万多小时。
The imported fiber laser, high performance, stability, life more than 100 thousand hours
●高速度，高效率，切割薄板每分钟速度可达数十米。
The high cutting speed and cutting efficiency, plate speed can reach up to 10 meters.
● 激光器免维护。
Laser - free maintenance;
●切割边缘质量好，变形小，外观平整，美观。
The small deformation of the edge or surface - smooth;
●采用进口导向传动机构和伺服电机，切割精度高。
The imported servo motor and drive system to ensure accurate cutting;
●可随意设计各种图形或文字即时切割，操作简单、灵活、方便。
Can freely design a variety of graphics or text immediately cut, the operation is simple, flexible and convenient
适用材料：Application
●适用于快速切割金属板或管，主要用于切割不锈钢、碳钢、锰钢、镀锌板、铝合金板、稀有金属。
Applicable to fast cutting on plate or tube in metal, mainly for cutting on SS,carbon steel, Manganese steel, galvanized plate, alloy plate, rare metal.
●广泛应用于厨房电气、钣金机箱机框、机框设备、电器设备、灯饰五金、广告标牌、汽车 配件、展示器材、各种金属制品、钣金切割加工等行业；
Widely used in kitchen appliance, electric control box, high-resolute device, mechanical equipment, electrical equipment, lighting, posters, auto parts, display equipment, hardware and metal processing.
技术参数technical parameter
| Model | XR-FLC3015 | XR-FLC4020 | XR-FLC6020 | |
| 加工幅面 Processing range |
3000*1500 |
4000*2000 |
6000*2000 | |
| 行程 stroke | 3025*1525*100 | 4030*2020*120 | 6030*2020*120 | |
| X/Y轴定位精度 X/Y axis location accuracy |
±0.03mm | |||
| X/Y重复定位精度 X/Y axis repeat location accuracy |
±0.02mm | |||
| 最大定位速度 Max. location speed | 169m/min | |||
| 最大加速度 Max. acceleration | 1G | |||
| 激光功率 laser power | 500W | 1000W | ||
| 切割厚度 Cutting thickness | ≤6mm | ≤12mm | ||
| 瞄准定位Positioning | 红光 red light | |||
| 整机耗电功率 Power consumption |
≤8kw |
≤20kw | ||
| 电力需求Power supply | 380V / 50Hz | |||
